Chapter 11 SELECTING PERIPHERAL EQUIPMENT
Table 11.4-21 DC Reactor (DCR) (Continued)
Power supply
voltage
Nominal
applied
motor
(kW)
Inverter type Mode
DC reactor
type
Rated
current
(A)
Inductance
(mH)
Generated
loss (W)
0.4 FRN0.4G1-4J DCR4-0.4 1.5 50 2
0.75 FRN0.75G1-4J DCR4-0.75 2.5 30 2.5
1.5 FRN1.5G1-4J DCR4-1.5 4 16 4.8
2.2 FRN2.2G1-4J DCR4-2.2 5.5 12 6.8
3.7 FRN3.7G1-4J
HD
DCR4-3.7 9 7 8.1
5.5 HD DCR4-5.5 13 4 10
FRN5.5G1-4J
LD
7.5
HD
DCR4-7.5 18 3.5 15
FRN7.5G1-4J
LD
11
HD
DCR4-11 25 2.2 21
FRN11G1-4J
LD
15
HD
DCR4-15 34 1.8 28
FRN15G1-4J
LD
18.5
HD
DCR4-18.5 41 1.4 29
FRN18.5G1-4J
LD
22
HD
DCR4-22A 49 1.2 35
FRN22G1-4J
LD
30
HD
DCR4-30B 71 0.86 35
FRN30G1-4J
LD
37
HD
DCR4-37B/
DCR4-37C
88/
88
0.70/
0.483
40/
63
FRN37G1-4J
LD
45
HD
DCR4-45B/
DCR4-45C
107/
107
0.58/
0.4
44/
69
FRN45G1-4J
LD
55
HD
DCR4-55B/
DCR4-55C
131/
131
0.47/
0.324
55/
78
FRN55G1-4J
LD
75
HD
DCR4-75C 178 0.23 97
FRN75G1-4J
LD
90
HD
DCR4-90C 214 0.2 111
FRN90G1-4J
MD/LD
110
HD
DCR4-110C 261 0.166 122
FRN110G1-4J
MD/LD
132
HD
DCR4-132C 313 0.148 159
FRN132G1-4J
MD/LD
160
HD
DCR4-160C 380 0.122 185
FRN160G1-4J
MD/LD
200
HD
DCR4-200C 475 0.098 218
FRN200G1-4J
MD/LD
220
HD
DCR4-220C 524 0.087 231
250 MD DCR4-250C 589 0.077 249
FRN220G1-4J
LD
280
HD
DCR4-280C 649 0.069 270
315 MD DCR4-315C 739 0.061 285
355
FRN280G1-4J
LD DCR4-355C 833 0.054 308
315 HD DCR4-315C 739 0.061 285
355 MD DCR4-355C 833 0.054 308
400
FRN315G1-4J
LD DCR4-400C 938 0.048 323
355 HD DCR4-355C 833 0.054 308
400 MD DCR4-400C 938 0.048 323
450
FRN355G1-4J
LD DCR4-450C 1056 0.043 338
400 HD DCR4-400C 938 0.048 323
450 MD DCR4-450C 1056 0.043 338
FRN400G1-4J
LD
500
HD
DCR4-500C 1173 0.039 384
FRN500G1-4J
LD
630
HD
DCR-630C 1477 0.031 620
Three-phase
400 V
710
FRN630G1-4J
LD DCR-710C 1666 0.028 600
(Note 1) A box () in the above table replaces an alphabetic letter depending on the enclosure.

S (Basic type), E (EMC filter built-in type)
