11.4 Option
11-83
Chapter 11 SELECTING PERIPHERAL EQUIPMENT
No. o19 o20 Input signal name Terminal function and configuration details
6) 0,1 5
4-digit BCD
frequency command
(0 to 500.0 Hz)
Frequency can be specified within the
range of 0 to 500.0 Hz (Setting
resolution = 0.1 Hz).
If a frequency command exceeding the
maximum output frequency is input, the
maximum output frequency applies.
7) 1 0 8-bit binary frequency command
Frequency setting range: -(Maximum
output frequency) to +(Maximum output
frequency)
-128 to +127
Setting resolution = Maximum output
frequency (1/127)
8) 1 1 12-bit binary frequency command
Frequency setting range: -(Maximum
output frequency) to +(Maximum output
frequency)
-2048 to +2047
Setting resolution = Maximum output
frequency (1/2047)
9) 1 2 15-bit binary frequency command
Frequency setting range: -(Maximum
output frequency) to +(Maximum output
frequency)
-16384 to +16383
Setting resolution = Maximum output
frequency (1/16383)
10) 1 3 16-bit binary frequency command
Frequency setting range: -(Maximum
output frequency) to +(Maximum output
frequency)
-32768 to +32767
Setting resolution = Maximum output
frequency (1/32767)
Note: "Without polarity" when o20 = 4 or 5 (BCD).
