11.4 Option
11-106
Table 11.4-82 Function Code Group
Group
Function
code
Name Group
Function
code
Name Group
Function
code
Name
S 2 02h
Command/function
data
A 9 09h
Motor 2
parameter
b 19 13h
Motor 3
parameter
M 3 03h Monitored data o 10 0Ah Option functions r 12 0Ch
Motor 4
parameter
F 4 04h Basic function J 14 0Eh
Application
functions 1
d 20 14h
Application
functions 2
E 5 05h Terminal functions y 15 0Fh Link function
C 6 06h Control function W 16 10h Monitored data 2
P 7 07h Motor 1 parameters X 17 11h Alarm 1
H 8 08h
High performance
functions
Z 18 12h Alarm 2
Example: For F26 F ⇒ Group code 04
26 ⇒ 1A (hexadecimal)
"041A"
Communications formats
The communications formats supported are listed below. The output formats should be selected by
function code o31 and the input formats by function code o32. Restarting the inverter validates the new
settings of o31 and o32.
Table 11.4-83 List of Communications Formats
o31, o32 Type Instance ID Details
Words
occupied
o31=20 20 Basic I/O Instance Output 4
o31=21 or 0
(Default)
21 Extended I/O Instance Output 4
o31=100 100 Fuji Drive Assembly Output 4
o31=102 102 Data Mapped I/O (Write) 8
o31=104 *
Output
(from master to
inverter)
104 Request for Access to Function Codes 8
o32=70 70 Basic I/O Instance Input 4
o31=71 or 0
(Default)
71 Extended I/O Instance Input 4
o32=101 101 Fuji Drive Assembly Input 4
o32=103 103 Data Mapped I/O (Monitor) 8
o32=105 *
Input
(from inverter to
master)
105 Response to Function Codes Access 8
*
When o31 is set at 104 (Request for Access to Function Codes) as the output format, o32 should be set
at 105 (Response to Function Codes Access). For details, refer to the instruction manual of the
DeviceNet communications card.
