Machine Components
45
Product Overview
2
îš„ Finisher A2 (optional)
1 Center tray
Copies or prints are delivered here.
2 Extension tray
Prevents outputs from falling off.
z
Extend the extension tray for landscape outputs.
3 Finisher A2
Staples copies or prints.
4 Staple cartridge
Contains staples. Remove this cartridge when replacing or adding staples, or clearing staple
jams.
5Front cover
Open this cover when replacing staples or clearing staple jams.
6Top cover
Open this cover to clear paper jams.
z
The Finisher A2 is optional. The common features of the Finisher A2, Finisher B1, and C3 Finisher described in
this guide are referred to as the "finisher".
