Product Overview
48
Product Overview
2
2 Hole-punch waste container
Collects punch scraps from the puncher. Remove this container when discarding the scraps.
3 Output tray
Outputs are delivered here.
4Finisher tray
Outputs are delivered here.
5 Staple cartridge
Staples are stored in this cartridge. Pull out this cartridge to replace staples or clear staple
jams.
6 Booklet tray
Bound booklets are delivered here.
7 Finisher front door
Open this door to clear paper or staple jams, replace staples, or discard punch scraps.
8 Booklet unit
This unit is for folding outputs in half and stapling the folded outputs.
9 Booklet staple cartridge
Two staple cartridges for booklet creation. Take out the cartridges when clearing stapled
jams, or when replacing them with new ones.
10 Tri-fold output tray (When the optional Folder Unit CD1 is installed)
Tri-folded outputs are delivered here.
11 Folder Unit cover (When the optional Folder Unit CD1 is installed)
Open this cover to clear paper jams.
12 Finisher transport center tray (Top cover of the finisher transport)
Copies and prints are delivered here when they are unable to be delivered to the output
tray or finisher tray. Pull the cover upward when clearing paper jams.
z
Remove outputs delivered to the center tray constantly.
z
The C3 Finisher and the C3 Finisher with Booklet Maker are optional. The common features of the Finisher
A2, Finisher B1, and C3 Finisher described in this guide are referred to as the "finisher".
