Documents with Different Widths
1 Align the top of the documents.
2 Place the documents at the center of the ADF paper chute
(feeder), and adjust the side guides to the widest
document in the batch.
For details, refer to "Chapter 2 How to Load Documents" (page 32).
4.2 Scanning Documents of Different Types and Sizes
ATTENTION
When you scan a mixed batch with different widths, some of the smaller
documents may be skewed or not fed into the ADF. In that case,
separate the documents by their widths, and scan them in different
batches.
HINT
For details about the conditions for documents that can be scanned in a
mixed batch, refer to the "Conditions for Mixed Batch Scanning" (page
41).
ATTENTION
Make sure that all documents are placed underneath the pick
roller. Otherwise, some documents may be skewed or not fed into
the ADF.
Width of the Pick Roller
Good
Width of the Pick Roller
Bad
