Fujitsu FI-800R User Manual

No. Name Function
1 Pick roller (× 1) A roller which feeds documents on the ADF paper chute
(feeder) into the ADF.
2 Ultrasonic sensor (× 2) A sensor which detects overlapped documents by
ultrasonic soundwave.
It detects overlapped documents by monitoring the
difference in the amount of ultrasonic waves transmitted
through the documents.
3 Document sensor (× 4) A sensor which detects whether there is a document.
4 Eject roller (× 8) A roller which ejects documents from the ADF.
5 Feed roller (× 4) A roller which feeds documents through the ADF.
6 Glass (× 2) The surface which scans documents.
7 Document loading detector (× 1) It detects whether a document is loaded or not in the ADF
paper chute (feeder).
8 Pad unit (× 1) A part which separates overlapped documents before they
are fed into the ADF.
Scanner Overview
22

Fujitsu FI-800R Specifications

General

Scanner Type	Document Scanner
Optical Resolution	600 dpi
ADF Capacity	20 sheets
Daily Duty Cycle	4, 500 sheets
Supported Operating Systems	Windows, macOS
Color Depth	24-bit
Document Feeder Capacity	20 sheets
Document Size	A4, A5, A6, B5, B6, Legal, Letter
Scan Speed (A4, 200 dpi)	40 ppm / 80 ipm
Maximum Document Size	216 mm x 356 mm
Scanning Speed	Simplex: 40 ppm (color, 200/300 dpi) Duplex: 80 ipm (color, 200/300 dpi)
