Parts and Functions
This section shows the names of the scanner parts.
Front Side
No. Name Function
1 ADF (Automatic Document Feeder) Pulls and feeds the documents one sheet at a time from
the return path opening or the ADF paper chute (feeder).
Open this to replace consumables or to clean the inside of
the scanner.
2 Chute extension Pull out to adjust to the document length.
3 ADF paper chute (feeder) Open the ADF paper chute (feeder) to load a document in
it.
There is an opening on the bottom of the ADF paper chute
(feeder).
4 Side guide Positions the documents in place when the documents are
loaded in the ADF paper chute (feeder) as they are fed into
the scanner.
5 Stacker Stacks up the ejected documents.
