Replacing the Consumables
This section explains how to replace the consumables for the scanner.
The inside of the ADF becomes very hot when the scanner is being used.
Before you replace the consumables, make sure to turn off the power, unplug the power
cable and wait for at least 15 minutes for the inside of the ADF to cool down.
Consumables and Replacement Cycles
Name Part No. Suggested Replacement Cycle
PAD Unit PA03795-0002 30,000 sheets or one year
PICK ROLLER PA03795-0001 150,000 sheets or one year
Consumables need to be replaced periodically. It is recommended that you keep a stock of new consumables
and replace them before it reaches the end of the consumable life. Also, the scanner records the number of
sheets scanned for each consumable (pad unit and pick roller), which allows you to determine when to replace
the consumables.
For information on how to check the number of sheets scanned, refer to Settings Related to Sheet Counters
(page 162).
Note that the suggested replacement cycles are guidelines for using A4 (80 g/m
2
[20 lb]) wood-free or wood-
containing paper, as these cycles vary depending on the type of documents scanned and how often the scanner
is used and cleaned.
HINT
Only use the specified consumables.
For information on purchasing the consumables, contact the distributor/dealer where you purchased this
product. Refer to the contact information in the Contact List if supplied with this product, or refer to the contact
