Power Connectors for the DMC-40x0
Overview
The DMC-40x0 uses Molex Pitch Mini-Fit, Jr.™ Receptacle Housing connectors for connecting DC Power to the
Amplifiers, Controller, and Motors. This section gives the specifications of these connectors. For information
specific to your Galil amplifier or driver, refer to the specific amplifier/driver in the Integrated Components section.
Molex Part Numbers Used
There are 3 different Molex connectors used with the DMC-40x0. The type of connectors on any given controller
will be determined be the Amplifiers/Drivers that were ordered. Below are tables indicating the type of Molex
Connectors used and the specific part numbers used on each Amplifier or Driver. For more information on the
connectors, go to 366Hhttp://www.molex.com/.
Note: These part number list the connectors that are found on the controller. For more information see the Molex
Website.
Molex Part Number Crimp Part Number Type
39-31-0060 44476-3112 6 Position
39-31-0040 44476-3112 4 Position
39-31-0020 44476-3112 2 Position
Galil Amplifier / Driver Molex Part Number Type
None 39-31-0020 2 Position
AMP-43040
Power 39-31-0060 6 Position
Motor 39-31-0040 4 Position
AMP-43140
Power 39-31-0040 4 Position
Motor 39-31-0020 2 Position
SDM-44040
Power 39-31-0060 6 Position
Motor 39-31-0040 4 Position
SMD-44140
Power 39-31-0060 6 Position
Motor 39-31-0040 4 Position
Appendices • 205 DMC-40x0 User Manual
