RS-422-Auxiliary Port (Non-Standard Option)
Standard connector and cable when DMC-40x0 is ordered with RS-422 Option.
Pin # Signal
1 CTS-
2 RXD-
3 TXD-
4 RTS-
5 GND
6 CTS+
7 RXD+
8 TXD+
9 RTS+
Ethernet
100 BASE-T/10 BASE-T - Kycon GS-NS-88-3.5
Pin # Signal
1 TXP
2 TXN
3 RXP
4 NC
5 NC
6 RXN
7 NC
8 NC
10 BASE-2- AMP 227161-7
10 BASE-F- HP HFBR-1414 (TX, Transmitter)
HP HFBR-2416 (RX, Receiver)
DMC-40x0 User Manual A5 – CMB-41012 (-C012) • 254
