Galil DMC-4040 - ICM-42200 Analog 15 Pin D-Sub Connector (Male)

ICM-42200 Analog 15 pin D-sub Connector (Male)
Pin # Label Description
1 AGND Analog Ground
2 AI1 Analog Input 1
3 AI3 Analog Input 3
4 AI5 Analog Input 5
5 AI7 Analog Input 7
6 AGND Analog Ground
7 -12V -12V
8 +5V +5V
9 AGND Analog Ground
10 AI2 Analog Input 2
11 AI4 Analog Input 4
12 AI6 Analog Input 6
13 AI8 Analog Input 8
14 N/C No Connect
15 +12V +12V
Jumper Description for ICM-42000
Jumper Label Function (If jumpered)
Q and P 1 Sink/Source Selection
2 Sink/Source Selection
3 Sink/Source Selection
4 HAEN/LAEN Selection
5 5V/12V/External Power Selection
6 5V/12V/External Power Selection
Note: See ICM-42200 Amplifier Enable Circuit in Chapter 3 for detailed information.
DMC-40x0 User Manual A8 – ICM-42200 (-I200) • 270
