Jumper Description for ICM-42000
Jumper Label Function (If jumpered)
Amplifier Enable GND Connect AECOM1 or AECOM2 to Digital Ground
+5V Connect AECOM1 or AECOM2 to Controller +5V
+12V Connect AECOM1 or AECOM2 to Controller +12V
AEC1 Connect AECOM1 to AEC1 pin on External Driver D-Sub
AEC2 Connect AECOM2 to AEC2 pin on External Driver D-Sub
Note: See ICM-42000 and ICM-42100 Amplifier Enable Circuit in Chapter 3 and
Configuring the Amplifier Enable Circuit in the Appendix for more information.
DMC-40x0 User Manual A6 – ICM-42000 (-I000) • 260
