Galil DMC-4040 - A5 - Cmb-41012 (-C012)

A5 – CMB-41012 (-C012)
Description
The CMB-41012 provides the connections for the Ethernet and Serial communication as well as the D-Sub
connector for the Extended I/O. The CMB-41012 also contains the 8x2 character LCD. See Chapter 3 for Electrical
Specifications of Extended I/O.
Connectors for CMB-41012 Interconnect Board
CMB-41012 Extended I/O 44 pin HD D-Sub Connector (Male)
Pin# Label Description Pin# Label Description Pin# Label Description
1 IO18 Configurable I/O bit 18 16 IO17 Configurable I/O bit 17 31 IO19 Configurable I/O bit 19
2 IO21 Configurable I/O bit 21 17 IO20 Configurable I/O bit 20 32 IO22 Configurable I/O bit 22
3 IO24 Configurable I/O bit 24 18 IO23 Configurable I/O bit 23 33 GND Digital Ground
4 IO26 Configurable I/O bit 26 19 IO25 Configurable I/O bit 25 34 IO27 Configurable I/O bit 27
5 IO29 Configurable I/O bit 29 20 IO28 Configurable I/O bit 28 35 IO30 Configurable I/O bit 30
6 IO32 Configurable I/O bit 32 21 IO31 Configurable I/O bit 31 36 GND Digital Ground
7 IO33 Configurable I/O bit 33 22 N/C No Connect 37 IO34 Configurable I/O bit 34
8 IO36 Configurable I/O bit 36 23 IO35 Configurable I/O bit 35 38 N/C No Connect
9 IO38 Configurable I/O bit 38 24 IO37 Configurable I/O bit 37 39 GND Digital Ground
10 N/C No Connect 25 N/C No Connect 40 IO39 Configurable I/O bit 39
11 IO41 Configurable I/O bit 41 26 IO40 Configurable I/O bit 40 41 IO42 Configurable I/O bit 42
12 IO44 Configurable I/O bit 44 27 IO43 Configurable I/O bit 43 42 IO45 Configurable I/O bit 45
13 IO47 Configurable I/O bit 47 28 IO46 Configurable I/O bit 46 43 GND Digital Ground
14 N/C No Connect 29 IO48 Configurable I/O bit 48 44 N/C No Connect
15 RES
Reserved
1
30 +3.3V
+3.3V
2
Notes:
1 5V when (5V) option is ordered on CMB. Ex DMC-4040-C012(5V)-I200
2 Reserved when (5V) option is ordered on CMB
DMC-40x0 User Manual A5 – CMB-41012 (-C012) • 252
