14 N/C No Connect 29 N/C No Connect 44 N/C No Connect
15 +5V +5V 30 N/C No Connect
Notes:
1 Negative differential motor command outputs when (DIFF) option is ordered on ICM. Ex DMC-4040-C012-I000(DIFF).
These pins may be used for other functions when (DIFF) option is not ordered.
A7 – ICM-42100 (-I100) • 263 DMC-40x0 User Manual
