Spreader - User Manual
39
position (percentage), used for the calibration procedure between 0 and 50%.
• Press the side keys near to the icons
and , to select in the CALIBRATION DIRECTION
parameter whether the calibration sequence starts with the shutter in the minimum opening
position and stops with the shutter in the maximum opening position or vice versa.
In the case of the parameter UNLOAD, the list allows selection of the unload hopper, left
or right.
• Press the side key near to the icon
to access the previous page;
• The key below the icon allow quit to the previous menu, not executing the calibration
procedure;
• Press the key below the icon to enter a sequence to store a calibration diagram
for the selected product. The calibration procedure is described below (see Calibration
procedure).
If the calibration sequence is performed in SIMPLE mode, the above described parameters will
not be displayed
