AT600 User’s Manual 1
Chapter 1. Introduction
Chapter 1. Introduction
1.1 Overview
Thank you for purchasing the AT600 ultrasonic flow meter. AT600 is a clamp-on ultrasonic flow meter for
measurement of liquid phase products. It is designed for the industrial market, including water, wastewater, steel,
campus energy and other markets. AT600 utilizes a new electronics platform and industrial design to make it extremely
simple to install and use in the field.
The AT600 consists of the new AT600 electronics, metal enclosure and field proven AT transducers system, including
the clamp-on fixture.
Figure 1: AT600 System (Pipe Mounting)
Transducer Cable
Electronic
U-Bolt
Power Cable
With Transducer Installed
Fixture
Strap
