Chapter 3. Initial Setup and Programming
3.6.2 Programming the Digital Output Menu
Digital outputs can be programmed as Pulse, Frequency or Alarm, or turned off.
To access the
Digital Output menu, on the initial screen, highlight the lock
symbol and press [√]. The following screen appears.
Select
Program and press [√]. The following screen appears.
To enter the password, use the [] or [] arrow key to select each digit to be
changed, use the [] or [] arrow keys to change the value of each digit, and
press
[]. The following screen appears.
In the User Preference menu, select Units Setting and press the right arrow key.
A screen similar to the following appears.
Select the desired Digital Output number with the [] or [] arrow keys, and
press
[] to enter the relevant configuration menu.
Note: The operation steps for “Digital Output B” and “Digital Output C” are
the same.
Velocity
m/s
0.0
Display
Display Format
Program
Program Review
Keypad Lockout
Enter the password
9999
]MOVE
]UNDO [ ]SAVE
]
]
]
]MODF
User Preference
Settings
Units Setting
Density
Password
Input/Output
Analog Output A
Digital Output B
Digital Output C
Modbus/Service Port
