AT600 User’s Manual 65
Chapter 3. Initial Setup and Programming
3.7.3b Setting a Special Transducer
Select Transducer and press [√]. The following screen appears.
Select
SPEC and press [√]. A screen similar to the following appears.
In the Special Transducer menu, select
Frequency and press [√]. The following
screen appears.
Select the appropriate option and press
[] twice to return to the previous screen.
Select
Wedge Type and press [√]. The following screen appears.
Sensor Setup
Meter Setup
Pipe
Transducer
Traverses
Transducer
SPEC
STD
Special Transducer
Frequency
Wedge Type
Wedge Angle
Wedge SOS
Frequency
0.5 Mhz
1 Mhz
2 Mhz
4 Mhz
Special Transducer
Frequency
Wedge Type
Wedge Angle
Wedge SOS
