Chapter 3. Initial Setup and Programming
58 AT600 User’s Manual
3.7.2 Programming the Pipe
3.7.2a Setting Pipe OD/ID/Wall Thickness
Note: Changing the Pipe ID (inner diameter) with automatically change the wall thickness. Changing the wall
thickness value will automatically change the Pipe ID.
Select
Pipe and press [√]. The following screen appears.
In the User Preference menu, select Pipe OD, Pipe ID or Wall Thickness and
press [√]. A screen similar to the following appears.
Press
[] again, and a screen similar to the following appears.
Note: The units that appear will be the units selected in Units Setting on page
28.
Use the [] or [] arrow key to select the digit to be changed, use the [] or
[] arrow keys to provide a new number and press
[] to save.
Repeat these steps to set the Pipe ID and Wall Thickness. Press [
] to return to
the Pipe menu.
Sensor Setup
Meter Setup
Pipe
Transducer
Traverses
Pipe
Pipe OD
Pipe ID
Wall Thickness
Pipe Material
Pipe OD
Pipe OD
89.760 mm
Pipe OD
UNIT: mm
89.76
0
]MOVE
]UNDO [ ]SAVE
]
]
]MODF
[
