AT600 User’s Manual 59
Chapter 3. Initial Setup and Programming
3.7.2b Setting Pipe Material
Table 2 below lists the preprogrammed pipe materials.
In the Pipe menu, select Pipe Material and press [√]. The following screen
appears.
Table 2: Preprogrammed Pipe Materials
Name Pipe Material
CARBON STEEL Carbon Steel
SS STEEL Stainless Steel
DUCT IRON Duct Iron
CAST IRON Cast Iron
Cu Cuprum
Al Aluminum
BRASS Brass
30%Ni 30% Nickel Copper Alloy
10%Ni 10% Nickel Copper Alloy
PYREX GLASS Pyrex Glass
FLINT GLASS Flint Glass
CROWN GLASS Crown Glass
NYLON PLSTC Nylon Plastic
POLYE PLSTC Polyethylene
POLYP PLSTC Polypropylene
PVC PLSTC Polyvinyl chloride
ACRYL PLSTC Acrylic Plastics
Select the appropriate option and press [
] to return to the previous screen.
If the material is not listed, select
Other and press [√] twice. A screen similar to
the following appears.
Pipe
Pipe OD
Pipe ID
Wall Thickness
Pipe Material
Pipe Material
CuNi
Glass
Plastic
Other
To Next Page
