Section 9 — Working with Routes
184
View Machine and Point Speed Details
To view current speed details for a machine or point:
1. Press or Record Review on the main menu.
2. Use the arrow keys to navigate to a point or machine.
TIP: Use and to move up and down. Use and to
collapse and expand items.
3. Press Edit Name — The screen displays the selected point
item's speed type, default speed, and RPM multiplier (if configured in
Ascent). It will also indicate whether the Ask user for speed checkbox
has been selected in Ascent. If you have selected a machine (rather
than a point), the screen will display the speed type and default
speed. It will also indicate whether the user will be asked to enter a
machine speed prior to taking the specified measurement. This
information is read-only, it cannot be edited.
Skip Route Entries and Machines
You can change the order in which you collect recordings. To do this, you
jump to a different position in the route. This enables you to skip
individual route entries, locations, or entire machines. It is useful if a
machine on your route is temporarily unavailable but will be available
for recording later in the day.
If you jump to a different position in a route, the instrument will pause
after each location's parameter sets have been recorded. This enables
you to continue to follow the route as it has been defined, or manually
choose the next route entry. Whenever you skip to a different position in
the route, your instrument will continue the route from that point
forward.
To skip individual entries or entire machines:
1. Use the arrow keys on the left to move the selection bar up or down.
2. Press repeatedly to expand a machine so its locations and
route entries become visible.
3. Press to start recording again at the selected position.
