GE MEDICAL SYSTEMS
D
IRECTION FK091075, REVISION 04 VIVID 3N PRO/EXPERT SERVICE MANUAL
6-2 Section 6-2 - Input AC Voltage Configuration
Section 6-2
Input AC Voltage Configuration
• The internal Vivid 3N voltage is 220V AC.
• The Back End and Front End Crates operate on 220V AC.
• The Monitor and Peripherals operate on local voltage.
6-2-1 Secondary Voltage Configuration
The AC input voltage is factory preset according to specific requirements, as indicated on the label near
the AC input connector. The AC transformer’s primary and secondary voltages are set up by using the
appropriate plugs connected in Jumper1 and Jumper2 on the AC Distribution Box, in accordance with
the information in Table 6-2 below:
6-2-2 AC Input Cord
The input voltage power cord and plug must meet the local standards and requirements.
Table 6-2 Primary and Secondary AC Voltages
Jumper 1
PRIMARY
Voltage
Range
100-120V 220-240V
Plug P/N
FK200077 FK200078
Jumper 2
SECONDARY
Voltage
100V 120V 220-230V 230-240V
Plug P/N
FK200079 FK200080 FK200084 FK200085
