Getting started
Vivid i User’s Manual 37
2378958-100 Rev. 02
Parameters window
Displays scan mode or application specific parameters. In
scanning mode the parameters for the active mode are
highlighted. This window also displays zoom information and
image groups in image browser.
Soft menu window
Displays the mode specific controls operated from the 4-way
rocker on the control panel. The mode-specific menus are
described in Chapter 3, "Scanning Modes" on page 75. For
operating procedure of the 4-way rocker see page 53.
Clipboard
Displays the thumbnail images representing the acquired data
during the current examination.
The status bar
Consists of four information fields as follows:
Service iLinq button (wrench icon)
Enable access to the GE Medical Systems on-line service
center.
Connectivity status icon
Displays the network status: Connected or disconnected.
Power & Battery status
Displays the power status. Amount of battery charge and if AC
adapter is connected (see page 14)
Prompt/status field
Displays system messages or prompts the user for actions.
Trackball assignments fields
Displays the available assignments of the trackball. The current
assignment is highlighted.
The acquisition window
Displays the ultrasound image with relevant indicators such as
depth, focus, probe orientation marker, physiological
traces...etc.
