Getting started
Vivid i User’s Manual 39
2378958-100 Rev. 02
5. Lift the connector locking lever (see Figure 1-9) upwards to
the full horizontal position to lock in place.
Figure 1-9: Probe Connection Locking Lever
6. Carefully position the probe cord so that it is free to move
and is not resting on the floor.
When the probe is connected, it is automatically activated.
Cable Handling
Take the following precaution with probe cables:
• Do not bend the cable acutely.
Deactivating the Probe
Press the FREEZE key to deactivate the probe. When
deactivating the probe, the probe is automatically placed in
Standby mode.
Disconnecting the Probe
Probes can be disconnected at any time. It is recommended
that the probe should not be active when being disconnected.
CAUTION
Fault conditions can result in electric shock hazard. Do not touch
the surface of probe connectors which are exposed when the
probe is removed. Do not touch the patient when connecting or
disconnection a probe.
