Connectors are for use of both cupper and aluminium cables, unless other is specified.
Accuracy of display readout (parameters 009-012):
Motor current [6] 0-140% load ........................................................... Max. error: ±2.0% of rated output current
Torque % [7], -100 - 140% load .................................................................. Max. error: ±5% of rated motor size
Output [8], power HP [9], 0-90% load ............................................................... Max. error: ±5% of rated output
Control characteristics:
Frequency range ................................................................................................................................ 0 - 1000 Hz
Resolution on output frequency ............................................................................................................ ±0.003 Hz
System response time .............................................................................................................................. 3 msec.
Speed, control range (open loop) .................................................................................. 1:100 of synchro. speed
Speed, control range (closed loop) .............................................................................. 1:1000 of synchro. speed
Speed, accuracy (open loop) ......................................................................... < 1500 rpm: max. error ± 7.5 rpm
>1500 rpm: max. error of 0.5% of actual speed
Speed, accuracy (closed loop) ...................................................................... < 1500 rpm: max. error ± 1.5 rpm
>1500 rpm: max. error of 0.1% of actual speed
Torque control accuracy (open loop) ............................................ 0- 150 rpm: max. error ±20% of rated torque
150-1500 rpm: max. error ±10% of rated torque
>1500 rpm: max. error ±20% of rated torque
Torque control accuracy (speed feedback) ......................................................... Max. error ±5% of rated torque
All control characteristics are based on a 4-pole asynchronous motor
Externals:
Enclosure ................................................................................................................................. IP 00, IP 20, IP 54
Vibration test .............................. 0.7 g RMS 18-1000 Hz random. 3 directions for 2 hours (IEC 68-2-34/35/36)
Max. relative humidity ............................................................................ 93 % (IEC 68-2-3) for storage/transport
Max. relative humidity ......................................... 95 % non condensing (IEC 721-3-3; class 3K3) for operation
Aggresive environment (IEC 721 - 3 - 3) ............................................................................. Uncoated class 3C2
Aggresive environment (IEC 721 - 3 - 3) ................................................................................. Coated class 3C3
Ambient temperature IP 20 (high overload torque 160%) ................. Max. 45

C (24-hour average max. 40

C)
Ambient temperature IP 20 (normal overload torque 110%) .............. Max. 40

C (24-hour average max. 35

C)
Ambient temperature IP 54 (high overload torque 160%) ................. Max. 40

C (24-hour average max. 35

C)
Ambient temperature IP 54 (normal overload torque 110%) .............. Max. 40

C (24-hour average max. 35

C)
Ambient temperature IP 20/54 VLT 5011 500 V ................................ Max. 40

C (24-hour average max. 35

C)
Derating for high ambient temperature, see the Design Guide
Min. ambient temperature in full operation ..................................................................................................... 0

C
Min. ambient temperature at reduced performance ................................................................................... -10

C
Temperature during storage/transport ........................................................................................... -25 - +65/70

C
Max. altitude above sea level ................................................................................................................... 1000 m
Derating for high air altitude, see the Design Guide
EMC standards applied, Emission ....................................... EN 50081-1/2, EN 61800-3, EN 55011, EN 55014
EMC standards applied, Immunity ........................... EN 50082-2, EN 61000-4-2, IEC 1000-4-3, EN 61000-4-4
EN 61000-4-5, ENV 50140, ENV 50141, VDE 0160/1990.12
See section on special conditions in the Design Guide
