Gehl RT210 User Manual

Maintenance
Printed in U.S.A. 145 50940411/G0219
WARNING
Keeps hands and feet clear from between the
track and the idler/roller wheels when installing
tracks. Crushing of body parts and amputation
can result.
10. Using a pry bar (A, Fig. 153) and wedging
blocks (U), pull/guide the new track at (R) over
the front idler wheel, and under the bottom
rollers. Carefully direct an assistant to start the
machine and direct the assistant to operate the
track drive slowly forward/back to work the
track over the front idler wheel.
NOTE:
Tie-down bracket (W) can be used as a
lever point for prying the track into place over the
front idler wheel.
IMPORTANT: Guides on the inside of the track
must straddle the front idler and bottom roller
wheels.
11. Make sure the new track is fully engaged around
the idler and roller wheels, and in the drive
sprocket, all the way around.
12. Remove any wedging blocks (U) that were used
to guide the track.
13. Remove the block placed under the track at (S,
Fig. 152).
14. The installed track should look similar to Fig.
154.
15. Start the machine, open the engine compartment
and press the bottom of the track tension service
switch (N, Fig. 155), to set the track tension
cylinders into the operating (extended) position.
Fig. 153 – Track Installation - Front
W
U
A
U
Fig. 154 – Track Installed Before Tensioning
X
N
Later Models RT175/RT210 Shown; Other
Machines Similar
Fig. 155 – Track Tension Switch

Gehl RT210 Specifications

General

Rated Operating Capacity	2, 100 lbs
Engine Make	Yanmar
Tipping Load	6000 lbs
Displacement	202 cu in
Hydraulic Pressure	3335 psi
Width	72 in
