66 Sabre Owner’s Guide
Error Cause Remedy
“ERROR: Table Bounds
Violation -X” (or +X, -Y, +Y)
G-code command attempted
to move outside of table active
job area.
Modify job so that all
movement stays within
active job area.
“Error: Table protect”
Depth of cut will cut into table
surface.
Adjust depth of cut or
material thickness.
Turn Table Protect OFF.
“FAULT IN X AXIS”
“FAULT IN Y AXIS”
“FAULT IN Z AXIS”
Motor servo amplifier fault. Check servo amplifier
wiring/circuitry.
“PLOT DATA COMMAND”
Illegal host GSPGL command
received.
Verify job type is “Gerber”.
Make sure ART Path version
is compatible with router
version.
“SPINDLE I/O FAILURE”
Spindle Controller is not
turned on.
Attempt to turn on spindle
without a tool.
Spindle Controller failure.
Make sure spindle controller
is on.
Install tool before turning on
spindle.
Check spindle controller
error codes.
“UART Card Not Found”
Could not locate UART card. Make sure UART card is
installed firmly into
connector and that all
connections are properly
made.
“UART OVERRUN”
Host communication not
responding to flow control.
Make sure host
communication serial port is
configured for proper flow
control.
“X AXIS”
“Y AXIS”
“Z AXIS”
Limit switch was tripped.
Could not move to 0,0 position
while Orienting.
Servo amplifier exceeded
maximum position error.
Power cycle and re-orient
router.
Check for obstruction to axis
movement.
Do not move carriage
beyond active job area.
Check Emergency Stop
cable/wiring.
“X ENCODER/MOTOR”
“Y ENCODER/MOTOR”
“Z ENCODER/MOTOR”
Encoder count indicates
insufficient or excess motion.
Check
wiring/encoder/motor.
Ensure that rear and/or
right Limit Switches are not
engaged at power-up or
have failed during job.
Check Emergency Stop
cable/wiring.
