7.1 Maintenance with open door
7.1.1 Attachment pin door
Removal
Remove the panel by unscrewing the four screws that hold the
plastic panel in place. Lift off the panel from its hook fastener on
each side. Then remove the nut that is on the front edge of the
door. Remove the old attachment pin.
Assembly
Position the new attachment pin and adjust it so that the door
closes with an even edge around the chamber. Put the panel back
by securing it in the hook fastener. Then attach the panel with the
four screws that holds it in place.
000440
Figure 11. Attachment pins on door
7 REPAIRS AND ADJUSTMENT
78 (128) TECHNICAL MANUAL GETINGE WD15 CLARO
