7.14.6 Calibrating temperature sensors – with resistance
Proceed as follows to calibrate the temperature sensors with the
aid of resistance:
1. Connect a PC with the CS 1000 program installed for the
disinfector.
2. Apply resistance for 20ºC at the following places:
• A01-X1 Chamber temperature 9A, 10A
• A01-X2 Independent chamber temperature 5A, 6A
3. Start CS 1000 and choose Settings/Calibration/Analog Input
Automatic...
000318
4. Click Temp chamber and Temp chamb indep(A), then click
Calibrate (B).
A B
000319
5. Enter the value 20 (C) and click Set Low.
6. Check that the value (D) rises to 20.
7 REPAIRS AND ADJUSTMENT
TECHNICAL MANUAL GETINGE WD15 CLARO 109 (128)
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
