Function Symbol Description
Alphabetical
keyboard
Shift from numerical to
alphabetical keyboard.
Information An incident has occurred.
During an ongoing process the
entire information message
appears in the process status
window.
Insufficient user
rights
No authorization for access to
the menu.
Scroll list If there are more rows than
space available on the process
screen, a scroll list is displayed
on the right. To reach the row
above or below, just continue
pressing on the cursor key.
2.2.3.6
Process management status
The keys displayed in the window below Process handling can
adopt three different states according to the below.
Symbol Status Description
Active The key can be pressed but is
not selected.
Selected The key is selected. Activation
takes place with .
Not available The key is currently not
available.
2.3 Software description and settings
This section describes the PACS 350 control and monitoring
system.
2 PRESENTATION
TECHNICAL MANUAL GETINGE WD15 CLARO 17 (128)
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
