7.2 Maintenance from the chamber
7.2.1 Replacing an element
Removal
• Remove the element holders that are placed around the
element coils.
• Loosen the nuts that are in the middle between the element
coils.
• Then pull the element coils up into the chamber.
• Loosen the cables and replace the element.
000438
Figure 12. Element holder
Assembly
• Connect the cables and make sure that the element reaches
the bottom properly before the nuts are tightened to get it
completely tight in the bottom of the chamber.
