Table 43: Internal Options/Hardware Config
Tone Region
Select country to set the default t
ones for dial tone, busy tone, ring tone
and etc to be sent from t
he FXS port. The default setting is "United
States of America (USA)".
Advanced Settings
FXO Opermode
Select country to set the
On Hook Speed, Ringer Impedance, Ringer
Threshold, Current Limiting, TIP/RING voltage adjustment, Minimum
Operational Loop Current, and AC Impedance
as predefined for your
country'
s analog line characteristics. The default setting is "United
States of America (USA)".
FXS Opermode
Select country to set the
On Hook Speed, Ringer Impedance, Ringer
Threshold, Current Limiting, TIP/RI
NG voltage adjustment, Minimum
Operational Loop Current, and AC Impedance
as predefined for your
country'
s analog line characteristics. The default setting is "United
States of America (USA)".
TISS Override
Select the impedance value for Two-Wire Impedance Synthesis (TISS)
override. The default setting is 600Ÿ.
PCMA Override
Select the codec to be used for analog lines. North Amer
ican users
should choose PCMU. All other countries, unless already known, should
be assumed to be PCMA. The default setting is PCMU.
Note:
This option requires system reboot to take effect.
Boost Ringer
Configure whether
normal ringing voltage (40V) or maximum ringing
voltage (89V) for analog phones attached to
the FXS port is required.
The default setting is "Normal".
Fast Ringer
Configure to increase the ringing speed to 25HZ. This option can be
used with "Low Power" option. The default setting is "Normal".
Low Power
Configure the peak voltage up to 50V
during "Fast Ringer" operation.
This option is used with "Fast Ringer". The default setting is "Normal".
Ring Detect
If set to "Full Wave", false ring detection will be prevented for lines where
Caller ID is sent before the first ring and proceeded by
a polarity
reversal, as in UK. The default setting is "Standard".
MWI Mode
Configure
the type of Message Waiting Indicator detection on trunk
(FXO) interfaces. The default setting is "None".
x None: No detection
x FSK: Frequency Shift Key detection
x NEON: Neon MWI detection
