Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 137 of 159

STATUS AND REPORTING

PBX STATUS

The UCM6100 monitors the status for Trunks, Extensions, Queues, Conference Rooms, Interfaces and

Parking lot. It presents administrators the real time status in different sections under web

GUI->Status->PBX Status.

Figure 62: Status->PBX Status

TRUNKS

Users could see all the configured trunk status in this section.

Figure 63: Trunk Status
