Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 79 of 159

matches the DID pattern, the call will be allowed to go through.

x Extension

x Voicemail

x Conference Room

x Queue

x Ringgroup

x Page

x Vmgroup

x Fax

x DISA

x IVR

DID Features

Dial Trunk

If enabled, external users calling into the UCM6100

can dial outbound

calls via the UCM6100 trunks by DID. The default setting is "No".

DID Destination

Select the DID destination. Only the selected category can be reached

by DID using this inbound route.

x User Extension. This is always selected by default.

x Conference

x Call Queue

x Ring Group

x Page/Intercom Group

x IVR

x Voicemail Groups

x Fax Extension

BLACKLIST CONFIGURATIONS

In the UCM6100, Blacklist is supported for all inbound routes. Users could enable the Blacklist feature,

manage the Blacklist by clicking on "Blacklist".
