Grandstream Networks UCM6108

Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 144 of 159
System Time Current system time.
The current system time is also available on the upper right of
each web page.
Up Time System up time since the last reboot.
Idle Time System idle time since the last reboot.
Boot Boot version.
Core Core version.
Base Base version.
Program Program version. This is the main software release version.
Recovery Recovery version.
NETWORK
Under Web GUI->Status->System Status->Network, users could check the network information for the
UCM6100. Please see details in the following table.
Table 61: System Status->Network
Status -> System Status -> Network
MAC Address Global unique ID of device, in HEX format. The MAC address can be found on the
label coming with original box and on the label located on the bottom of the device.
IP Address IP address.
Gateway Default gateway address.
Subnet Mask Subnet mask address.
DNS DNS Server address.
STORAGE USAGE
Users could access the storage usage information from Web GUI->Status->System Status->Storage
Usage. It shows the available and used space for the following partitions.
x Configuration partition
This partition contains PBX system configuration files and service configuration files.
x Data partition
Voicemail, recording files, IVR file, music on hold files and etc.
x USB disk
USB disk will display if connected.
x SD Card
