Grandstream Networks UCM6108 User Manual

Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 24 of 159
Select "All On" "All Off" or "Blinking" and check LED status.
x RTC Test Patterns
Select "2022-02-22 22:22" or "2011-01-
11 11:11" to start the RTC
(Real-
Time Clock) test pattern. Then check the system time from LCD idle
screen by pressing "DOWN" button, or from web GUI->System
Status->General page. Reboot the device manually after the RTC test is
done.
x Hardware Testing
Select "Test SVIP" to perform SVIP test on the device. This is mainly for
factory testing purpose which verifies the hardware connection inside the
device. The diagnostic result will display in the LCD after the test is done.
Web Info
x Protocol: Web access protocol. HTTP or HTTPS. By default it's HTTPS
x Port: Web access port number. By default it's 8089
USE THE LED INDICATORS
The UCM6100 has LED indicators in the front to display connection status. The following table shows the
status definitions.
Table 5: UCM6102/UCM6104 LED INDICATORS
LED Indicator LED Status
LAN
WAN
USB
SD
FXS (Phone/Fax)
FXO (Telco Line)
Solid: Connected
Flashing: Data Transferring
OFF: Not Connected
Table 6: UCM6108/UCM6116 LED INDICATORS
LED LED Status
NETWORK
Solid: Connected
OFF: Not Connected
ACT
USB
SD
Phone (FXS)
Line (FXO)
Solid: Connected
Flashing: Data Transferring
OFF: Not Connected
