Grandstream Networks UCM6108 User Manual

Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 115 of 159
Table 38: Event List Settings
URI
Configure
the name of this event list (for example, office_event_list).
Please note the URI name
cannot be the same as the extension name
on the UCM6100. The valid characters are letters, digits, _ and -.
Local Extensions
Select the available extensions listed on the local UCM6100 to be
monitored in the event list.
Remote Extensions
If LDAP sync is
enabled between the UCM6100 and the peer UCM6100,
the remote extensions will be listed under "Available Extensions". If not,
manually enter the remote extensions under "Special Extensions" field.
Special Extensions
Manually enter the remote extensions in the peer/register
trunk to be
monitored in the event list.
Valid format: 5000,5001,9000
Remote extension monitoring works on the UCM6100 via event list BLF, among Peer SIP trunks or
Register SIP trunks (register to each other). Therefore, please properly configure SIP trunks on the
UCM6100 first before using remote BLF feature. Please note the SIP end points need support event list
BLF in order to monitor remote extensions.
When an event list is created on the UCM6100 and remote extensions are added to the list, the UCM6100
will send out SIP SUBSCIRBE to the remote UCM6100 to obtain the remote extension status. When the
SIP end points registers and subscribes to the local UCM6100 event list, it can obtain the remote
extension status from this event list.
Once successfully configured, the event list page will show the status of local extensions, remote
extensions, subscribers for each event list. Users can also select the remote event URI to check the
subscribers' details.
Figure 58: Event List Status
