Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 33 of 159
Table 9: UCM6108/UCM6116 Network Settings->Basic Settings
Preferred DNS Server Enter the preferred DNS server address.
IP Method Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Gateway IP Enter the gateway IP address for static IP settings.
Subnet Mask Enter the subnet mask address for static IP settings.
IP Address Enter the IP address for static IP settings.
DNS Server 1 Enter the DNS server 1 address for static IP settings.
DNS Server 2 Enter the DNS server 2 address for static IP settings.
User Name Enter the user name to connect via PPPoE.
Password Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value
is 0.
Layer 2 QoS 802.1p
Priority Value
Assign the priority value of the lay
er 2 QoS packets for LAN port. The default
value is 0.
802.1X
The UCM6100 provides users 802.1X settings for LAN port and WAN port (UCM6102 only).
Table 10: UCM6100 Network Settings->802.1X
802.1X Mode
Select 802.1X mode. The de
fault setting is "Disable". The supported 802.1X
mode are:
x EAP-MD5
x EAP-TLS
x EAP-PEAPv0/MSCHAPv2
Identity Enter 802.1X mode identity information.
MD5 Password Enter 802.1X mode MD5 password information.
802.1X Certificate Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
