Table 4: LCD Menu Options

View Events

x Critical Events

x Other Events

Device Info

x Hardware: Hardware version number

x Software: Software version number

x P/N: Part number

x WAN MAC: WAN side MAC address (UCM6102 only)

x LAN MAC: LAN side MAC address

x Uptime: System up time

Network Info

For UCM6104/UCM6108/UCM6116:

x LAN Mode: DHCP, Static IP, or PPPoE

x LAN IP: IP address

x LAN Subnet Mask

For UCM6102:

x WAN Mode: DHCP, Static IP, or PPPoE

x WAN IP: IP address

x WAN Subnet Mask

x LAN IP: IP address

x LAN Subnet Mask

Network Menu

For UCM6104/UCM6108/UCM6116:

x LAN Mode: Select LAN mode as DHCP, Static IP or PPPoE

For UCM6102:

x WAN Mode: Select WAN mode as DHCP, Static IP or PPPoE

Factory Menu

x Reboot

x Factory Reset

x LCD Test Patterns

Press "OK" to start. Then press

"Down" button to test different LCD

patterns. When done, press "OK" button to exit.

x Fan Mode

Select "Auto" or "On".
