Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 29 of 159
SYSTEM SETTINGS
This section explains configurations for system-wide parameters on the UCM6100. Those parameters
include Network Settings, Firewall, Change Password, LDAP server, HTTP server, Email settings, Time
Settings and NTP Server settings.
NETWORK SETTINGS
After successfully connecting the UCM6100 to the network for the first time, users could login the Web GUI
and go to Settings->Network Settings to configure the network parameters for the device.
The network setting options are similar for UCM6108 and UCM6116. Additional network functions and
settings are available for UCM6102 and UCM6104:
x UCM6102 supports Route/Switch/Dual mode functions.
x UCM6104 supports Switch/Dual mode functions.
In this section, all the available network setting options are listed for each model. Select each tab in web
GUI->Settings->Network Settings page to configure LAN settings, WAN settings (UCM6102 only),
802.1X and Port Forwarding (UCM6102 only).
BASIC SETTINGS
Please refer to the following tables for basic network configuration parameters on UCM6102, UCM6104,
and UCM6108/UCM6116 respectively.
Table 7: UCM6102 Network Settings->Basic Settings
Method
Select "Route", "Switch" or "Dual" mode on the network interface of UCM6102.
The default setting is "Route".
x Route
WAN port interface will be used for uplink connection. LAN port interface will
be used to serve as router.
x Switch
WAN port interface will be used for uplink connection. LAN port interface will
be used as bridge for PC connection.
x Dual
