Grandstream Networks UCM6108 User Manual

Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 30 of 159
Both ports can be used for uplink connection. Users will need assign LAN 1
or LAN 2 as the default interface in option "Default Interface"
and configure
"Gateway IP" for this interface.
Preferred DNS Server Enter the preferred DNS server address.
WAN (when "Method" is set to "Route")
IP Method Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Gateway IP Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
Subnet Mask
Enter the subnet mask address for static IP settings.
The default setting is
255.255.0.0.
IP Address Enter the IP address for static IP settings. The default setting is 192.168.0.160.
DNS Server 1
Enter the DNS server 1 address for static IP settings.
The default setting is
0.0.0.0.
DNS Server 2 Enter the DNS server 2 address for static IP settings.
User Name Enter the user name to connect via PPPoE.
Password Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN Tag
Assign the VLAN tag of the layer 2 QoS packets for WAN port. The default value
is 0.
Layer 2 QoS 802.1p
Priority Value
Assign the priority value of the layer 2 QoS packets for W
AN port. The default
value is 0.
LAN (when Method is set to "Route")
IP Address Enter the IP address assigned to LAN port. The default setting is 192.168.2.1.
Subnet Mask Enter the subnet mask. The default setting is 255.255.255.0.
DHCP Server Enable Enable or disable DHCP server capability. The default setting is "Yes".
DNS Server 1 Enter DNS server address 1. The default setting is 8.8.8.8.
DNS Server 2 Enter DNS server address 2. The default setting is 208.67.222.222.
Allow IP Address From Enter the DHCP IP Pool starting address. The default setting is 192.168.2.100.
Allow IP Address To Enter the DHCP IP Pool ending address. The default setting is 192.168.2.254.
Default IP Lease Time Enter the IP lease time (in seconds). The default setting is 43200.
LAN (when Method is set to "Switch")
IP Method Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
IP Address Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Gateway IP Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
Subnet Mask
Enter the subnet mask address for static IP settings.
The default setting is
255.255.0.0.
DNS Server 1 Enter the DNS server 1 address for static IP settings.
The default setting is
