Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 50 of 159
Please make sure an extension is manually assigned to the phone or "Automatically Assign Extension" is
enabled first. After the configuration on the UCM6100 web GUI, click on "Save" and "Apply Changes". Then
reboot the phones to have the provisioning process started. Once the phone picks up the config file from the
UCM6100, it will reboot again to take the configuration.
MANUAL PROVISIONING
DISCOVERY
Users could manually discover the device by specifying the IP address or scanning the entire network.
Three methods are supported to scan the devices.
x PING
x ARP
x SIP Message (NOTIFY)
Click on "Auto Discover", fill in the "Scan Method" and "Scan IP". The IP address segment will be
automatically filled in based on the network mask detected on the UCM6100. If users need scan the entire
network segment, enter 255 (for example, 192.168.40.255) instead of a specific IP address. Then click on
"Save" to start discovering the devices within the same network. To successfully discover the devices,
"Zero Config" needs to be enabled on the UCM6100 web GUI->PBX->Basic/Call Routes->Zero
Config->Auto Provisioning Settings.
Figure 22: Auto Discover
The following figure shows a list of discovered phones. The MAC address, IP Address, Extension (if
assigned), Version, Vendor, Model, Connection Status, Create Config, Options (Edit/Delete) are displayed
in the list.
Figure 23: Discovered Devices
