Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 46 of 159

NTP SERVER

The UCM6100 can be used as a NTP server for the NTP clients to synchronize their time with. To configure

the UCM6100 as the NTP server, set "Enable NTP server" to "Yes" under web GUI->Settings->Time

Settings->NTP Server. On the client side, point the NTP server address to the UCM6100 IP address or

host name to use the UCM6100 as the NTP server.
