Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 31 of 159
0.0.0.0.
DNS Server 2 Enter the DNS server 2 address for static IP settings.
User Name Enter the user name to connect via PPPoE.
Password Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN Tag
Assign the VLAN tag of the layer 2 QoS packets for L
AN port. The default value
is 0.
Layer 2 QoS 802.1p
Priority Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default
value is 0.
LAN 1 / LAN 2 (when Method is set to "Dual")
Default Interface
If "Dual" is selected as "Method", users will need assign the default interface to
be LAN 1 (mapped to UCM6102 WAN port) or LAN 2 (mapped to UCM6102 LAN
port) and then configure network settings for LAN 1/LAN 2. The default interface
is LAN 2.
IP Method Select DHCP, Static IP, or PPPoE. The default setting is DHCP.
Gateway IP Enter the gateway IP address for static IP settings. The default setting is 0.0.0.0.
IP Address Enter the IP address for static IP settings. The default setting is 192.168.0.160.
Subnet Mask
Enter the subnet mask address for static IP settings.
The default setting is
255.255.0.0.
DNS Server 1
Enter the DNS server 1 address for static IP settings.
The default setting is
0.0.0.0.
DNS Server 2 Enter the DNS server 2 address for static IP settings.
User Name Enter the user name to connect via PPPoE.
Password Enter the password to connect via PPPoE.
Layer 2 QoS
802.1Q/VLAN Tag
Assign the VLAN tag of the layer 2 QoS packets for LAN port. The default value
is 0.
Layer 2 QoS 802.1p
Priority Value
Assign the priority value of the layer 2 QoS packets for LAN port. The default
value is 0.
Table 8: UCM6104 Network Settings->Basic Settings
Method
Select "Switch" or "Dual" mode on the network interface of UCM6104. The
default setting is "Switch".
x Switch
LAN 1 port interface will be used for uplink connection. LAN 2 port interface
will be used as bridge for PC connection.
x Dual
Both ports can be used for uplink connection. Users will need assign the
