Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 135 of 159
Max Registration/Subscription
Time
Configure the maximum duration
(in seconds) of incoming registration
and subscription allowed by the UCM6100. The default setting is 3600.
Min Registration/Subscription
Time
Configure the minimum duration
(in seconds) of incoming registration
and subscription allowed by the UCM6100. The default setting is 60.
Music On Hold Interpret
Configure the Music On Hold class
for the channel when being put on
hold. This is used when the Music On Hold class is not set on the
channel and the peer channel placing the call on hold doesn't have
"Music On Hold Suggest".
Music On Hold Suggest
Configure the Music On Hold class to suggest to the peer channel when
placing the peer on hold.
Enable Relaxed DTMF Select to enable relaxed DTMF handling. The default setting is "No".
DTMF Mode
Select DTMF mode to send DTMF. The default setting is RFC2833. If
"Info" is selected, SIP INFO m
essage will be used. If "Inband" is
selected, 64-
kbit codec PCMU and PCMA are required. When "Auto" is
selected, "RFC2833" will be used if offered, otherwise "Inband" will be
used. The default setting is "RFC2833".
RTP Timeout
During an active call, if there is no RTP activity within the
timeout (in
seconds), the call will be terminated. The default setting is no timeout.
Note:
This setting doesn't apply to calls on hold.
RTP Hold Timeout
When the call is on hold, if there is no RTP activity within the timeout (in
seconds), the call will be terminated. This value of RTP Hold Timeout
should be larger than RTP Timeout. The default setting is no timeout.
Trust Remote Party ID
Configure whether the Remote-Party-ID should be trusted.
The default
setting is "No".
Send Remote Party ID
Configure whether the Remote-Party-ID should be sent or not. The
default setting is "No".
Generate In-Band Ringing
Configure whether the UCM6100 should generate inband ringing or not.
The default setting is "Never".
x Yes: The UCM6100
will send 180 Ringing followed by 183 Session
Progress and in-band audio.
x No: The UCM6100
will send 180 Ringing if 183 Session Progress
has not been sent yet. If audio path is established already with 183
then send in-band ringing.
x Never: Whenever ringing occurs, the UCM6100
will send 180
Ringing as long as 200OK has not been set yet. I
nband ringing will
not be generated even the end point device is not working properly.
