Grandstream Networks UCM6108 User Manual

Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 55 of 159
default setting is deactivated.
Call Forward No Answer
Configure the Call Forward No Answer target number. If not configured,
the Call Forward No Answer feature is deactivated. The default setting is
deactivated.
Call Forward Busy
Configure the Call Forward Busy target number. If not configured, the
Call Forward Busy feature is deactivated.
The default setting is
deactivated.
Ring Timeout
Configure the number of seconds to ring the user before
the call is
forwarded to voicemail (voicemail is enabled) or hang up (voicemail is
disabled). If not specified, the default ring timeout is 60 seconds on the
UCM6100, which can be configured in the global ring timeout setting
under web GUI->Internal Options->IVR Prompt: General Preference.
The valid range is between 5 seconds and 600 seconds.
Note:
If the end point also has a ring timeout configured, the actual ring
timeout used is the shortest time set by either device.
Technology
SIP
Select "SIP" if the user is using SIP or a SIP device.
The default setting
is enabled.
IAX
Select "IAX" if the user is using IAX or a IAX device.
The default setting
is disabled.
Analog Station
Select the FXS port if the user is att
ached on the analog port of the
UCM6100. The default setting is "None".
SIP Settings
NAT
Use NAT when the UCM6100 is on a public IP communicati
ng with
devices hidden behind NAT (e.g., broadband router). If there is one-way
audio issue, usually it's related to NAT configuration or Firewall's support
of SIP and RTP ports. The default setting is enabled.
Can Reinvite
By default, the UCM6100 will route the media steams from SIP
endpoints through itself. If enabled, the PBX will
attempt to negotiate
with the endpoints to route the media stream directly. It
is not always
possible for the UCM6100 to negotiate endpoint-to-
endpoint media
routing. The default setting is "No".
DTMF Mode
Select DTMF mode for the user to send DTMF. The default setting is
"RFC2833".
If "Info" is selected, SIP INFO message will be used. If
"Inband" is selected, 64-kbit
PCMU and PCMA are required. When
"Auto" is selected, RFC2833 will be used if offered, otherwise "Inband"
