Firmware Version 1.0.2.21 UCM6100 Series IP PBX User Manual Page 71 of 159
Password Enter the password to register to the trunk from the provider.
Auth ID
This is
the authentication ID for the UCM6100 to register to the trunk if
required by the provider. If not specified, the CallerID name will be sued
for authentication.
Codec Preference
Select audio and video codec for the VoIP trunk. The available codecs
are: PCMU, PCMA, GSM, AAL2-G.726-32
, G.722, G.729, G.723, ILBC,
ADPCM, LPC10, H.264, H.263, H.263p.
From Domain
Configure the actual domain name where the extension comes from.
This can be used to override the From Header.
For example, "trunk.UCM6100.provider.c
om" is the From Domain in
From Header: sip:1234567@trunk.UCM6100.provider.com.
From User
Configure the actual user name of the extension. This can be used to
override the From Header. There are cases where there is a single ID
for registration (single trunk) with multiple DIDs.
For example, "1234567" is the From User in From Header:
sip:1234567@trunk.UCM6100.provider.com.
Outbound Proxy Support Select to enable outbound proxy in this trunk. The default setting is "No".
Outbound Proxy
When outbound proxy
support is enabled, enter the IP address or URL
of the outbound proxy.
Enable Qualify
If enabled, the UCM6100 will regularly send SIP OPTIONS to the device
to check if the device is still online. The default setting is "No".
Qualify Timeout
When "Enable
Qualify" option is set to "Yes", configure the timeout (in
ms) for the Qualify SIP message. If no response is received within the
timeout, the device is considered offline. The default setting is 1000ms.
Qualify Frequency
When "Enable Qualify" option is
set to "Yes", configure the interval (in
seconds) of the SIP OPTIONS message sent to the device to check if
the device is still online. The default setting is 60 seconds.
Fax Detection
Enable to detect Fax signal from the trunk during the call and send the
received Fax to the default Email address in Fax setting page under web
GUI->PBX->Internal Options->Fax/T.38.
Note:
If enabled, Fax Pass-through cannot be used.
SRTP Enable SRTP for the VoIP trunk. The default setting is "No".
Peer IAX Trunk Configuration Parameters
Provider Name Configure the provider name for the VoIP trunk. This is a unique label to
