99
1: Vlan-interface200
Protocol: igmp, UpTime: 00:04:25, Expires: never
(10.1.1.100, 225.1.1.1)
Protocol: pim-dm, Flag: ACT
UpTime: 00:06:14
Upstream interface: Tunnel0
Upstream neighbor: 50.1.1.1
RPF prime neighbor: 50.1.1.1
Downstream interface(s) information:
Total number of downstreams: 1
1: Vlan-interface200
Protocol: pim-dm, UpTime: 00:04:25, Expires: never
The output shows that Switch A is the RPF neighbor of Switch C and the multicast data from Switch A is
delivered over an IPv4 over IPv4 tunnel to Switch C.
Troubleshooting multicast routing and forwarding
Static multicast route failure
Symptom
No dynamic routing protocol is enabled on the routers, and the physical status and link layer status of
interfaces are both up, but the static multicast route fails.
Analysis
• If the static multicast route is not configured or updated correctly to match the current network
conditions, the route entry and the configuration information of static multicast route do not exist in
the multicast routing table.
• If a better route is found, the static multicast route might also fail.
Solution
1. Use the display multicast routing-table static command to view the information of static multicast
routes to verify that the static multicast route has been correctly configured and that the route entry
exists in the multicast routing table.
2. Check the type of the next hop interface of the static multicast route. If the interface is not a
point-to-point interface, be sure to specify the next hop address for the outgoing interface when
you configure the static multicast route.
3. Check that the static multicast route matches the specified routing protocol. If a protocol was
specified in static multicast route configuration, enter the display ip routing-table command to
check if an identical route was added by the protocol.
4. Check that the static multicast route matches the specified routing policy. If a routing policy was
specified when the static multicast route was configured, enter the display route-policy command
to check the configured routing policy.
