Hammer B3 User Manual

15
A1 A2B
C2
C1
D
E
Saw-Spindle Moulder
B3 / B3 e-classic
Machine Standard Option
Sliding table length A
950 mm 1250 mm
Sliding table travel distance A1
459 mm 764 mm
Sliding table travel distance A2
660 mm 1028 mm
total length A1 + B + A2
2035 mm 2708 mm
Length: Machine table + bar B
916 mm
Overall width C1
844 mm
Overall width ( C2
892 mm 1743 mm
Total height / Working height (approx.) 1555 / 888 mm
Rip capacity D
700 mm
Width of sliding table E
290 mm
Net weight *) 240 kg
Machine including packaging
Length x Width **) 1200 x 800 mm
Height 1200 mm
Weight (approx.)* 310 kg
*) with average-sized equipment
**) The transport width measures under 800 mm. This makes it possible to transport the machine through doorways.
4.1.1 B3 basic/B3 e-classic
Fig. 4-1: Dimensions B3 basic/e-classic
4 Specifications
4.1 Dimensions and weight
Specifications
